Switched JST-PH 2-Pin SMT Right Angle Breakout Board

Switched JST-PH 2-Pin SMT Right Angle Breakout Board


In stock


Availability: 2 in stock SKU: AD1863 Categories: ,


This switched JST connector is the best way to quickly prototype with our LiPoly batteries. We paired a genuine JST connector with a slide switch that can do up to 600mA. Both are soldered onto a breadboard-friendly breakout. There's two ground pins, one 'switched' power pin, and one pin that is always on. This is compatible with the “JST PH 2-pin” connectors we use in our battery packs.. Mates perfectly with all our 1-cell LiPoly and LiIon batteries as well as our 6V coin cell holder and 3xAAA battery pack. We also have simple JST pigtails that mate with this connector.


21mm x 10mm x 2mm / 0.8″ x 0.4″ x 0.08″
Height with JST: 7.3mm
Weight: 1g

Datasheet for 2-pin R/A connector
Datasheet for the onboard switch – we parallel-connected both switches

Additional information

Weight 0,05 kg
Dimensions 5 × 1 × 3 cm
